LG Refrigerator 01
Touch · LCD · Reflector Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification 4.3”
- LCD Resolution : 480*RGB*272
- Available Touch : Full Touch
Product Specifications
| Applicable Products | Pull Touch (capacitive) + Key Touch | Display Mode | Normally Black |
|---|---|---|---|
| Size (Inch) | 4.3” TFT LCD | Brightness | 1000cd/m2 |
| Resolution | 480*RGB*272 | Touch Type | Full Touch (capacitive) |
LG Refrigerator 02
Metal Touch Assembly
- Product Overview
- Developing, mass-producing, and supplying metal door touch button modules
- Specification
- Touch sensitivity: 70 g/f
- SUS thickness: 0.7 T
Product Specifications
| Applicable Products | Refrigerator | SUS Thickness | 0.7T |
|---|---|---|---|
| Touch Method | Piezo | No. of Touches | 4 |
| Touch Sensitivity | 70g/f |
LG Washers / Dryers
Touch · LCD · Reflector Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification 2.4”
- LCD Resolution : 240*RGB*320
- Available Touch : Key Touch
Product Specifications
| Applicable Products | Washer / Dryer | Display Mode | Normally Black |
|---|---|---|---|
| Size (Inch) | 2.4.” TFT LCD | Brightness | 700cd/m2 |
| Resolution | 240*RGB*320 | Touch Type | Key Touch (capacitive) |
LG Washer Dryer Combos
Metal Touch Assembly
- Product Overview
- Developing, mass-producing, and supplying metal door touch button modules
- Specification
- Touch sensitivity: 70 g/f
- SUS thickness: 0.7 T
Product Specifications
| Applicable Products | Washer Dryer Combo | SUS Thickness | 0.7T |
|---|---|---|---|
| Touch Method | Piezo | No. of Touches | 1(3) |
| Touch Sensitivity | 70g/f |
LG Stylers
Touch · LCD · Reflector Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification2.4”
- LCD Resolution : 240*RGB*320
- Available Touch : Full Touch + Key Touch
Product Specifications
| Applicable Products | Styler | Display Mode | Normally Black |
|---|---|---|---|
| Size (Inch) | 2.4.” TFT LCD | Brightness | 700cd/m2 |
| Resolution | 240*RGB*320 | Touch Type | Pull Touch (capacitive) + Key Touch |
LG Floor-Standing Air Conditioners
Touch · LED or LCD · Reflector Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification 4.3”
- LCD Resolution : 480*RGB*272
- Available Touch : Key Touch
Product Specifications
| Applicable Products | Air Conditioner | Display Mode | Normally Black |
|---|---|---|---|
| Size (Inch) | 4.3” TFT LCD | Brightness | 1000cd/m2 |
| Resolution | 480xRGBx272 | Touch Type | Key Touch (capacitive) |
LG Commercial Floor-Standing Air Conditioners
Touch · LED or LCD · Reflector Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification 4.3”
- LCD Resolution : 480*RGB*272
- Available Touch : Key Touch
Product Specifications
| Applicable Products | Air Conditioner | Display Mode | Normally Black |
|---|---|---|---|
| Size (Inch) | 4.3” TFT LCD | Brightness | 1000cd/m2 |
| Resolution | 480*RGB*272 | Touch Type | Full Touch (capacitive) |
LG Central Control System
Touch · LCD · SET Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification
- LCD Resolution : 480*RGB*272, 800*RGB*480
- Available Touch : Key Touch
Product Specifications
| Applicable Products | Central Control System | |
|---|---|---|
| Size (Inch) | 4.3” TFT LCD | 10.1” TFT LCD |
| Resolution | 480*RGB*272 | 1024*RGB*600 |
| Display Mode | Normally Black | Normally Black |
| Brightness | 700cd/m2 | 280cd/m2 |
| Touch Type | Key Touch (capacitive) | Full Touch (capacitive) |
LG Air Purifiers /
Humidifiers
Touch · LCD · Reflector Assembly
- Product Overview
- Developing, mass-producing, and supplying LCD touch modules (capacitive)
- Specification 2.4”, 4.3”
- LCD Resolution : 240*RGB*320, 480*RGB*272
- Available Touch : Key Touch, Full Touch
Product Specifications
| Applicable Products | Air Purifier / Humidifier | |
|---|---|---|
| Size (Inch) | 2.4” TFT LCD | 4.3” TFT LCD |
| Resolution | 240*RGB*320 | 480*RGB*272 |
| Display Mode | Normally Black | Normally Black |
| Brightness | 1000cd/m2 | 700cd/m2 |
| Touch Type | Key Touch (capacitive) | Full Touch (capacitive) |
